347/347H Stainless Steel Plates, Buy Large Or Small Quantity Stainless Steel 347 Sheet, SS 347H Shim Sheets, UNS S34700 Perforated Sheets Supplier in Mumbai, India.
DIN 1.4550 Sheets, ASTM A240 SS 347 Hot Rolled Plate Manufacturer, DIN 1.4961 Cold Rolled Plates, 347 Chequered Plate Manufacturer in India.
Jade Special Metals is a known exporter and trader of SS 347 / 347H Sheets & Plates, which are designed by using high grade factor inputs and advanced technology in compliance with defined industry standards. These Stainless Steel 347 Sheets are highly appreciated for superior finish, compact designs, rigid construction, corrosion & chemical resistance and durability. In Stainless Steel 347 Plates, solution treatment is carried out at temperatures and for times sufficient to produce the required properties and the material is then cooled to prevent 475-degree C embrittlement. Providing higher strength than both austenitic and 22 percent Cr, Stainless Steel 347 Coils is suited to a variety of applications in industries such as Chemical Processing, Oil & Gas, and Marine environments. Stainless Steel 347H Sheets is considered to feature resilient to pitting, high strength, SCC, erosion weathering and oxidization fatigue, crevice rust and potency weldability. Stainless Steel 347H Plates has an excellent microstructure which contributes to their high strength and high resistance to stress corrosion cracking. Stainless Steel 347H Coils, Stainless Steel 410l Plate is often used in Chemical Process Industry, such as for Nitric Acid Processes, Polypropylene Production, Caustic Evaporators, Equipment Handling Organic and Fatty Acids. Stainless Steel UNS S34700 Sheets & Plates exhibits a low coefficient of thermal expansion and higher heat conductivity than austenitic steels and is suitable for working temperatures up to 300 Degree C.
Quick Section Links
- Stainless Steel 347/347H Sheets & Plates Specifications
- 347 / 347H Stainless Steel Sheets & Plates Equivalent Standard Grade
- Stainless Steel 347 / 347H Sheets & Plates Inventory
- Stainless Steel 347/347H Sheets & Plates Chemical Composition
- SS 347/347H Sheets & Plates Mechanical Properties
- Available Stock of ASTM A240 Stainless Steel 347 / 347H Sheets & Plates
- Applications of Stainless Steel 347 / 347H Sheets & Plates
Stainless Steel 347/347H Sheets & Plates Specifications
Standard : | ASTM A240 / ASME SA240 |
Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
Thickness : | 4 mm To 100 mm |
Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
Surface : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
Form : | Sheets, Plates, Coils, Slatting Coils, Perforated Coils |
Finish : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
“Contact Jade Special Metals today with your requirement for 347 Stainless Steel Sheet and 347H SS Plates. We assure you of the best quote.
347 / 347H Stainless Steel Sheets & Plates Equivalent Standard Grade
STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN |
SS 347 | 1.4550 | S34700 | SUS 347 | 08Ch18N12B | X6CrNiNb18-10 |
SS 347H | 1.4961 | S34709 | SUS 347H | – | X6CrNiNb18-12 |
Stainless Steel 347 / 347H Sheets & Plates Inventory
Stainless Steel 347/347H Perforated Sheets
Stainless Steel 347/347H Chequred Plates
Stainless Steel 347/347H Shim Sheets
Stainless Steel 347/347H Coils
Stainless Steel 347/347H Foils
Stainless Steel 347/347H Strips
Stainless Steel 347/347H Sheets & Plates Chemical Composition
Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
SS 347/347H Sheets & Plates Mechanical Properties
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Available Stock of ASTM A240 Stainless Steel 347 / 347H Sheets & Plates
- Stainless Steel 347 Shim Sheets
- SS 347H Circles
- 347 Stainless Steel Plain Sheets
- 347 Stainless Steel Foils
- UNS S34700 Polished Plates
- WERKSTOFF NR. 1.4550 Perforated Sheet
- ASTM A240 347H Stainless Steel Sheet
- Stainless Steel 347 Sheet Cut To Size
- Stainless Steel 347H Sheet #4 Finish
- 347 SS Cold Rolled Plates
- ASTM A240 Type 347 Plate 2B Finish
- 347H Stainless Steel Plate Mill Finish
- UNS S34709 Plates
- WERKSTOFF NR. 1.4961 Shim Sheets
- ASTM A240 AISI 347H Coils
- ASTM A240 347H SS Slitting Coil
- Stainless Steel 347H CR Sheet
- Stainless Steel 347 Strips
- 347H Stainless Steel #4 Finish Sheets
- 347 Stainless Steel Foils
- UNS S34700 Sheet Supplier
- WERKSTOFF NR. 1.4550 HR Plates
- 347H Austenitic Stainless Steel Sheet
- SS 347H #8 Finish Plates
- SS 347 Plate Manufacturer
- 347H Stainless Steel Laser Cutting Sheet
- Jindal Stainless Steel 347 Sheets
- 347 Stainless Steel Sheets Distributor
- UNS S34709 Plates Exporter
- WERKSTOFF NR. 1.4961 CR Sheets
- ASTM A240 Type 347 Sheet and Plate
- ASTM A240 347H Stainless Steel Plate
- 1.4961 Stainless Steel Perforated Sheet
- SS 347H 2B Finish Plates Stockist
- AISI 347 Sheets
- Stainless Steel 347H Sheets Price
Applications of Stainless Steel 347 / 347H Sheets & Plates
- Pipeline Engineering
- Marine Industry
- Chemical Industry
- Oil & gas industry
- Mechanical Engineering
- Plant Engineering
- Petrochemical Industry
- Power Industry
- Aerospace
- Food Processing Industry
