Inconel 600 Plate, Inconel 600 Sheet, Alloy 600 Plate, Alloy 600 Sheet and ASTM B168 UNS N06600 Manufacturer & Supplier in India
We have been supplying Inconel 600 Sheets & Plates from our Mumbai warehouse for over 15 years to aerospace fabricators, EPC contractors, chemical plant engineers, nuclear power operators and oil and gas OEMs across more than 50 countries. Every plate and sheet we supply is ASTM B168 / ASME SB168 certified to UNS N06600 and ships with an EN 10204 3.1 Mill Test Certificate on every shipment, not on request.
Inconel 600 (Werkstoff Nr. 2.4816, JIS NCF 600, EN NiCr15Fe) is a solid-solution nickel-chromium alloy that performs reliably across a wider temperature and chemical environment range than any standard grade of stainless steel. It is the material engineers specify when operating conditions, chloride exposure, temperatures above 700°C, alternating oxidising and reducing atmospheres or nuclear coolant environments rule out the cheaper options.
Our warehouse carries the full product range: foil from 0.15 mm to heavy plate at 120 mm, cold-rolled and hot-rolled, in all standard finishes. Laser cutting, shearing, circle cutting and custom slitting are done in-house. If you need cut-to-size rather than full sheets, just specify your dimensions when enquiring.
In Stock & Ready to Ship — Request Mill-Direct Price
Call / WhatsApp: +91 9987685906 | Email: sales@jadealloys.com | Contact Us
Why Inconel 600 Resists Chloride Stress Corrosion Cracking
Chloride stress corrosion cracking (Cl-SCC) is one of the most dangerous failure modes in process plant engineering. It requires three conditions simultaneously: a susceptible material, tensile stress (residual or applied), and chloride ions above a threshold concentration at elevated temperature. Austenitic stainless steels, including 316L and 304L, are highly susceptible — failures can occur with no visible prior warning at chloride levels as low as 50 ppm above 60°C.
Inconel 600 is immune because its ≥72% nickel content places the alloy above the electrochemical threshold at which chloride-induced anodic dissolution — the driving mechanism of Cl-SCC can sustain itself. This is a thermodynamic immunity, not a kinetic resistance: the cracking mechanism literally cannot initiate in a high-nickel alloy under the conditions that destroy stainless steel. This is why Inconel 600 is specified for nuclear steam generator tube support plates, seawater heat exchanger shells, and brine handling equipment worldwide.
Key Properties at a Glance
Oxidation resistance to 1093°C (self-healing Cr₂O₃ scale) │ Absolute Cl-SCC immunity by chemistry, not coating │ Dual oxidising/reducing environment resistance │ Carburisation and sulfidation resistance for petrochemical and furnace service │ Solid-solution strengthened — weld and form without precipitation hardening risk
Inconel 600 Sheets & Plates Specifications — ASTM B168, ASME SB168, AMS 5540
All Inconel 600 Sheets & Plates supplied by Jade Alloys comply with the following international standards. Mill Test Certificates referencing each applicable standard are provided with every order.
| Property | Details |
|---|---|
| Standard | ASTM B168 / ASME SB168 / AMS 5540 |
| UNS Designation | N06600 |
| Werkstoff Nr. | 2.4816 |
| JIS Equivalent | NCF 600 |
| EN Designation | NiCr15Fe |
| BS Designation | NA 13 |
| Thickness Range | 0.15 mm (foil) to 120 mm (heavy plate) |
| Width | 1000 mm, 1219 mm, 1500 mm, 1800 mm, 2000 mm, 2500 mm, 3000 mm (custom on request) |
| Length | 2000 mm, 2440 mm, 3000 mm, 5800 mm, 6000 mm (cut-to-size available) |
| Surface Finish | 2B, 2D, 2E, 2R (BA), No.1, No.4, No.8, Mirror (8K), Hairline, Brushed, Sand Blast, Checkered, Embossed |
| Form | Sheets, Plates, Coils, Slitting Coils, Foils, Strips, Shim Sheets, Perforated Sheets, Circles |
| Finish Type | Hot Rolled (HR), Cold Rolled (CR), 2B, 2D, BA, No.8, Satin with Plastic Coating |
| NACE Compliance | MR0175 documentation available on request |
| HSN Code | 75062000 |
| MTC | EN 10204 3.1 (standard) │ EN 10204 3.2 via SGS / Bureau Veritas (on request) |
| Lead Time | 2–5 business days (standard sizes) │ 3–7 days (cut-to-size or polished finishes) |
Equivalent International Grades of Inconel 600 / UNS N06600
| Standard | Werkstoff Nr. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel 600 Sheets & Plates Chemical Composition and Mechanical Properties
Chemical Composition (wt%) — UNS N06600 / Werkstoff Nr. 2.4816
The composition below reflects ASTM B168 requirements. The minimum 72% nickel content is the critical threshold for chloride SCC immunity. Any material failing to meet the 72% Ni minimum should be rejected regardless of the supplier’s stated grade.
Si (max)
| Grade | C (max) | Mn (max) | S (max) | Cu (max) | Fe | Ni (min) | Cr | |
|---|---|---|---|---|---|---|---|---|
| Inconel 600 | 0.15 | 1.00 | 0.50 | 0.015 | 0.50 | 6.00–10.00 | 72.00 min | 14.00–17.00 |
Inconel 600 Sheets & Plates Mechanical Properties — Room Temperature and Elevated Temperature
The table below includes standard room-temperature values per ASTM B168 and indicative elevated-temperature data from ASM and Nickel Institute handbook sources. Elevated-temperature data is provided as engineering reference only — verify against your specific heat treatment condition and heat number MTC for critical applications.
| Property | Test Temp | Tensile Strength | Yield Strength (0.2%) | Elongation |
|---|---|---|---|---|
| Room Temperature (20°C) | 20°C | 655 MPa (95,000 psi) | 310 MPa (45,000 psi) | 40% |
| Elevated Temperature | 315°C | ~620 MPa | ~270 MPa | 38% |
| Elevated Temperature | 540°C | ~570 MPa | ~240 MPa | 35% |
| Elevated Temperature | 760°C | ~430 MPa | ~200 MPa | 30% |
| Elevated Temperature | 1000°C | ~175 MPa | ~140 MPa | 55% |
Physical and Thermal Properties of Inconel 600 (Alloy 600 / 2.4816)
Thermal conductivity and coefficient of thermal expansion (CTE) data are critical for heat exchanger design, thermal stress analysis, and fabrication planning. The values below are for annealed material at the stated temperatures.
| Property | Value |
|---|---|
| Density | 8.47 g/cm³ (0.306 lb/in³) |
| Melting Range | 1354°C – 1413°C (2470°F – 2575°F) |
| Specific Heat (0–100°C) | 444 J/kg·K |
| Modulus of Elasticity | 214 GPa (31.1 × 10⁶ psi) |
| Thermal Conductivity (at 100°C) | 15.9 W/m·K |
| Electrical Resistivity (at 20°C) | 1.03 μΩ·m |
| Mean CTE (20–100°C) | 13.3 × 10⁻⁶ /°C |
| Magnetic Permeability | 1.010 (essentially non-magnetic) |
Inconel 600 Sheet & Plate Standard Thickness Range, Dimensions and Weight Reference
The table below covers our standard stocked thickness range with approximate weight per square metre calculated at the alloy density of 8.47 g/cm³. Use these values for freight estimation and procurement planning.
| Thickness (mm) | Thickness (inches) | Weight (kg/m²) |
|---|---|---|
| 0.15 – 0.40 | 0.006″ – 0.016″ | 1.3 – 3.4 |
| 0.5 | 0.020″ | 4.2 |
| 0.8 | 0.031″ | 6.8 |
| 1.0 | 0.039″ | 8.5 |
| 1.2 | 0.047″ | 10.2 |
| 1.6 | 0.063″ | 13.6 |
| 2.0 | 0.079″ | 16.9 |
| 3.0 | 0.118″ | 25.4 |
| 4.0 | 0.157″ | 33.9 |
| 5.0 – 6.0 | 0.197″ – 0.236″ | 42.4 – 50.8 |
| 8.0 – 10.0 | 0.315″ – 0.394″ | 67.8 – 84.7 |
| 12.0 – 25.0 | 0.472″ – 0.984″ | 101.6 – 211.8 |
| 30.0 – 50.0 | 1.181″ – 1.969″ | 254.1 – 423.5 |
| 60.0 – 120.0 | 2.362″ – 4.724″ | 508.2 – 1016.4 |
| Thickness | Weight (kg/m²) | Thickness | Weight (kg/m²) | Thickness | Formula |
|---|---|---|---|---|---|
| 1 mm | 8.47 kg | 6 mm | 50.82 kg | 25 mm | Weight = t(mm) × W(m) × L(m) × 8.47 |
| 2 mm | 16.94 kg | 10 mm | 84.7 kg | 50 mm | Example: 3mm × 1.5m × 3m × 8.47 = 114.3 kg |
| 3 mm | 25.41 kg | 12 mm | 101.6 kg | 100 mm | Contact us — weight-based FOB pricing available |
Surface Finishes Available for Inconel 600 Sheet & Plate
The correct surface finish selection depends on the application environment, hygienic requirements, and downstream processing. The table below describes each available finish with its key dimensional parameters and primary application area.
| Finish | Thickness Range | Max Width | Roughness (Ra) |
|---|---|---|---|
| No.1 | 2.4–120 mm | 2032 mm | ≥3.0 μm |
| 2D | 0.4–6.35 mm | 1524 mm | 0.5–1.0 μm |
| 2B | 0.25–8.0 mm | 2032 mm | 0.1–0.5 μm |
| 2E | 0.4–8.0 mm | 2032 mm | 0.5–1.0 μm |
| 2R (BA) | 0.25–3.5 mm | 1524 mm | <0.1 μm |
| No.4 | 0.5–4.0 mm | 1524 mm | 0.3–0.6 μm |
| No.8 (8K) | 0.5–4.0 mm | 1524 mm | <0.05 μm |
| Hairline (HL) | 0.5–3.0 mm | 1524 mm | 0.3–0.5 μm |
| Checkered / Embossed | 0.8–3.0 mm | 1500 mm | n/a |
Welding, Forming & Machining Inconel 600 Sheet — Complete Fabrication Guide
Inconel 600 is one of the more weldable high-nickel alloys, but its work-hardening rate, thermal expansion coefficient, and sensitivity to sulphur contamination require attention during fabrication. The guidance below reflects best practices for typical industrial fabrication.
Recommended Welding Processes and Filler Metals for Inconel 600
All standard fusion welding processes are applicable. The choice of filler metal is critical — always use a matching or higher-nickel filler to avoid creating dilution zones with degraded corrosion resistance.
| Process | Filler Metal | AWS Classification | Notes & Best Use |
|---|---|---|---|
| GTAW / TIG | ERNiCrFe-7 | AWS A5.14 | Preferred for precision welds, thin sheet, and root passes. Best corrosion resistance in weld zone. |
| GTAW / TIG | ERNiCr-3 | AWS A5.14 | Alternative for general TIG welding; slightly higher strength deposit. |
| SMAW | ENiCrFe-3 | AWS A5.11 | Field welding and repair. Good deposition rate. Use for structural work where access limits TIG. |
| GMAW / MIG | ERNiCrFe-7 | AWS A5.14 | Higher deposition rate for production welding on thicker material (>6 mm). |
| SAW | ERNiCr-3 | AWS A5.14 | Heavy plate joining (>12 mm). Requires fluoride-basic flux. High productivity. |
| EBW / LBW | No filler | n/a | Electron beam / laser welding for thin-gauge aerospace and nuclear applications requiring minimal heat input. |
Pre-heat: Not required for Inconel 600 under standard fabrication conditions. Maintain interpass temperature below 150°C to control distortion in thin sheet.
Post-Weld Heat Treatment (PWHT): Not mandatory, but solution annealing at 980°C (1800°F) for 1 hour per 25 mm of thickness, followed by rapid cooling, is recommended for assemblies exposed to stress-corrosion risk or high-temperature cycling service. The anneal relieves residual weld stresses and re-dissolves any carbide precipitation in the heat-affected zone.
Critical contamination warning: Do not allow sulphur-bearing materials (marking inks, lubricants, some adhesives) to contact the metal surface during or before welding. Sulphur at temperature causes severe hot cracking in nickel alloy welds. Use only nickel-compatible lubricants and marking materials.
Cold Forming, Hot Forming and Machining Guidelines for Alloy 600
Cold Forming: Inconel 600 cold-forms well on standard press brake and roll-forming equipment, but work-hardens approximately 30–40% faster than 316L austenitic stainless. As a practical rule, increase the inside bend radius by 50% compared to the equivalent 316L operation. For tight-radius bends (< 1.5× material thickness), solution anneal the blank at 980°C before forming to achieve maximum ductility. Anneal again after significant cold work to restore corrosion resistance and avoid residual stress.
Hot Forming: Carry out between 870°C and 1175°C. The alloy becomes increasingly resistant to deformation below 870°C and risks cracking if forced. Above 1175°C, grain growth accelerates and mechanical properties degrade. After hot forming, always solution anneal to restore the full corrosion resistance of the alloy.
Machining: Use carbide tooling with positive rake angles and sharp cutting edges. Surface speeds should be 20–30% lower than for austenitic stainless steel — approximately 20–30 m/min for turning with carbide inserts. Use high feed rates and keep the tool engaged to prevent work-hardening the machined surface ahead of the cut. Flood coolant (water-soluble cutting fluid) is essential. Do not use sulphurised cutting oils.
Inconel 600 vs Inconel 625 vs Inconel 601 — How to Choose the Right Alloy
The three most frequently compared Inconel grades for high-temperature and corrosion-resistant applications are 600, 625, and 601. Each occupies a distinct performance envelope and price point. The comparison below covers the properties that drive specification decisions.
| Property | Inconel 600 (N06600) | Inconel 625 (N06625) | Inconel 601 (N06601) |
|---|---|---|---|
| Nickel Content | 72% min | 58% min | 58–63% |
| Chromium | 14–17% | 20–23% | 21–25% |
| Molybdenum | Not present | 8–10% | Not present |
| Aluminium | Not present | Not present | 1.0–1.7% (key differentiator) |
| Niobium | Not present | 3.15–4.15% | Not present |
| Max Service Temp. | 1093°C (2000°F) | 982°C (1800°F) | 1175°C (2150°F) — highest of three |
| Tensile Strength | 655 MPa | 930 MPa | 650 MPa |
| Cl-SCC Resistance | Excellent | Excellent | Excellent |
| Oxidation Resist. | Excellent to 1093°C | Good to 982°C | Superior above 1050°C |
| Pitting Resistance | Good | Superior (Mo) | Good |
| Relative Cost | Base (lowest) | +25–35% | +10–15% |
| ASTM Std (sheet) | ASTM B168 | ASTM B443 | ASTM B168 |
| Choose when… | High-temp + Cl-SCC risk; budget is a constraint | Seawater / strong acid / offshore / high mechanical load | Continuous >1050°C; high-aluminium oxidation scale required |
Inconel 625 → Maximum corrosion resistance in seawater, strong acids, and offshore applications.
Inconel 601 → Continuous service above 1050°C where aluminium-enhanced oxidation resistance is required.
Applications of Inconel 600 Plates & Sheets by Industry
The following table details the key applications of Inconel 600 flat-rolled products by industry, and critically explains what specific failure mode the alloy prevents that drives the specification decision. Engineers do not specify Inconel 600 because it is the ‘best’ alloy in general; they specify it because the operating conditions create a specific failure mode that cheaper alternatives cannot survive.
- Aerospace: Jet engine heat shields, turbine seals, exhaust liners, bleed-air ducting
- Chemical Processing: Chemical reactors, heat exchangers, distillation columns, evaporators, pressure vessels
- Nuclear Power: Steam generator tube support plates, reactor core components, spent fuel handling
- Oil & Gas: Downhole tubing, wellhead components, pressure vessels, separators
- Petrochemical: Ethylene dichloride cracking furnaces, steam reformers, pyrolysis coils
- Heat Treatment: Furnace muffles, retorts, radiant tubes, roller hearth components
- Power Generation: Gas turbine components, superheater headers, flue gas systems
- Food Processing: Sterilisation equipment, high-temperature processing vessels, conveyor components
- Marine / Offshore: Seawater piping, heat exchanger tubesheets, offshore platform components
- Pharmaceutical: Reactor vessels, distillation equipment, sterilisation chambers
Inconel 600 Sheet & Plate Price — India FOB, CIF & Export Pricing
Inconel 600 plate prices are driven primarily by the LME (London Metal Exchange) nickel index, since the alloy is over 72% nickel by weight. A $1,000/MT move in nickel translates to approximately $720/MT movement in alloy raw material cost. For this reason, quotations are tied to the LME nickel spot rate on the day of issue and are valid for 24–48 hours only.
| Price Parameter | Details |
|---|---|
| Export Price (plates, FOB Mumbai) | $33 – $38 per kg |
| Metric Tonne Price | $33,000 – $38,000 per metric ton |
| Price Basis | Indexed to daily LME nickel spot rate — nickel = 72%+ of alloy weight |
| Quote Validity | 24–48 hours from date of quotation |
| MOQ | No minimum for standard sizes — project quantities welcome |
| Incoterms Available | EXW, FOB, CIF, CFR, DAP |
| Form Premium | HR plate: base price │ CR sheet 2B: +5–10% │ Polished No.4/No.8: +15–25% |
| Thickness Premium | <1 mm thin gauge: +10–15% │ >50 mm heavy plate: +8–12% |
| Quantity Discount | <500 kg: +10–15% vs. MT price │ 1 MT+: standard rate │ 5 MT+: preferential rate |
| Certification Premium | EN 10204 3.1 MTC: included │ EN 10204 3.2 (TPI): +3–5% |
Available Stock of ASTM B168 Inconel 600 Sheets & Plates — Mumbai Warehouse
Our Mumbai warehouse holds the following Inconel 600 flat-rolled product forms in ready stock. Standard sizes are available for dispatch within 2–5 business days. Cut-to-size, polished, and custom-slit orders are processed in-house with typical lead times of 3–7 days.
Inconel 600 Sheets & Plates
- Inconel 600 Shim Sheets
- Alloy 600 Circles
- 600 Inconel Plain Sheets
- 600 Inconel Alloy Foils (thickness < 0.15 mm)
- UNS N06600 Polished Plates
- Werkstoff Nr. 2.4816 Perforated Sheet
- ASTM B168 600 Inconel Sheet
- Inconel 600 Sheet Cut To Size
- Inconel 600 Sheet #4 Finish
- Alloy 600 Cold Rolled Plates
- ASTM B168 Type 600 Plate 2B Finish
- 600 Inconel Plate Mill Finish
- UNS N06600 Plates
Inconel 600 Coils & Strips
- Werkstoff Nr. 2.4816 Shim Sheets
- ASTM B168 Alloy 600 Coils
- ASTM B168 Alloy 600 Slitting Coil
- Inconel 600 CR Sheet
- Inconel Alloy 600 Strips
- 600 Inconel Laser Cutting Sheet
- Alloy 600 #8 Finish Plates
- Werkstoff Nr. 2.4816 HR Plates
- Alloy 600 2B Finish Plates
- Inconel 600 Coils
- 600 Inconel Sheets Distributor
- UNS N06600 Plates Exporter
- Werkstoff Nr. 2.4816 CR Sheets
Frequently Asked Questions — Inconel 600 Sheets & Plates
What is Inconel 600 and what is it used for?
How much does Inconel 600 plate cost per kg in India?
Which ASTM standard covers Inconel 600 sheets and plates?
What is the difference between Inconel 600 and Inconel 625?
What is the maximum service temperature of Inconel 600?
Is Inconel 600 available in both cold-rolled and hot-rolled forms?
What filler metals should I use when welding Inconel 600?
What are the main industrial applications of Inconel 600 sheets and plates?
Does Jade Alloys offer third-party inspection (TPI) for Inconel 600 orders?
How do I calculate the weight of an Inconel 600 plate or sheet?
Countries We Export Inconel 600 Sheets & Plates
Jade Alloys is headquartered in Mumbai, Maharashtra — India’s primary industrial metals hub and the gateway to JNPT (Jawaharlal Nehru Port Trust / Nhava Sheva), the country’s largest container port. Our central Mumbai location enables fast dispatch to all major export markets.
Need Inconel 600 sheet delivered to your location? Contact our export team for freight terms, documentation, and lead time.
